Metabo HPT NR83AA5M Clipped Head Framing Nailer, 2" to 3-1/4"

Box Count
1
SKU
NR83AA5M
$259.00
FREE SHIPPING
Metabo HPT NR83AA5M Clipped Head Framing Nailer, 2" to 3-1/4" NR83AA5M

Box Count: 1

$259.00
Qty:
In Stock,Subject To Manufacturer Availability This item is shipped directly from the manufacturer to you
Qty:
In Stock,Subject To Manufacturer Availability This item is shipped directly from the manufacturer to you. In the event there is a delay in shipping due to availability, We will contact you via email within one business day of your order being placed.
Free Shipping
Product Overview

The Metabo HPT NR83AA5M (formerly HItachi) air-powered framing nailer drives clipped head paper tape strip nails from 2" to 3-1/4" in length, and offset round head paper strip nails from 2" to 3-1/4" in length. This paper tape framing nailer comes with a five-year professional warranty for peace of mind. Lightweight and well-balanced, this Metabo framing nailer is easy to maneuver, and capable of driving into the toughest materials.

Relying on the same cylinder valve drive system as the original Hitachi NR83AA from the 1980's, the NR83AA5 offers rapid response firing - paired with some serious driving power for quick and consistent sinking. Standard features on the NR83AA5M include a selective action trigger, to switch between contact and sequential operation, as well as a rear loading aluminum magazine, open nose design, hardened claw tip (to reduce wear and drive nails at different angles), rafter hook, tool-free depth adjustment, and a comfortable rubber grip.

With the selective actuation now located on the trigger, the NR83AA5M not only reduces the total number of parts in the trigger, but also eliminates all composite parts. This tool also includes an additional thin, contact only trigger. The Metabo HPT NR83AA5M is intended for applications including framing, sheathing, truss building, sub-flooring, decking, fencing and pallet assembly.

This item is identical to the Hitachi NR83AA5, which replaced the previously discontinued NR83AA3, NR83AA4, and all other preceding models.

WARNING: California residents, this item qualifies for Proposition 65 legislation.
Related Fasteners Specifications
  • Resources
  • Box Count 1
  • SKU NR83AA5M
  • UPC 717709023901
  • Power Type Pneumatic
  • Collation Type Paper Tape Strip
  • Application Type Framing, Sheathing, Subfloor
  • Brand Metabo HPT
  • Maximum Fastener Length 3-1/4"
  • Condition New
  • Case/Bag Included No
  • Included In Box Safety Glasses, Additional Thin Contact Trigger
  • Manufacturer's Warranty Five-Year Limited
  • Item Width 4-1/4"
  • Special Features Open Nose Design, Cylinder Valve
  • Item Height 14-3/16"
  • Item Length 18-1/8"
  • Magazine Capacity 86-94
  • Country of Manufacture China
  • Item Weight 9.0 lbs. w/out Hook, 9.3 lbs. w/ Hook
  • Usage Type Interior, Exterior
  • Minimum Fastener Length 2"
  • Housing Material Aluminum, Other Materials
  • Operating Pressure 70 to 120 PSI
  • Firing Type Selective
  • Air Inlet Size 3/8" NPT
  • Air Consumption .088 SCFM
  • Product Type Nailer
  • Depth Control Yes
  • Power Source Air
  • Special Offer Available No
  • Diameter Range .113" to .131"
  • Product Degree/Angle 30-34 Degree
  • Magazine Type Strip
  • Fastener Type Framing Nail
